This Southwire SIMpull THHN/THWN-2 wire is a 6 AWG stranded copper building wire in green, supplied on a 2500 ft reel. It is used in conduit and cable trays for service, feeder and branch circuits in commercial and industrial applications, and the green jacket is commonly chosen where a color-coded conductor is wanted.

• Brand: Southwire
• Part number: 20497407
• Color: Green
• Package: 2500 ft reel
• Voltage rating: 600 volts
• Conductor: 6 AWG, 19-strand soft drawn annealed bare copper
• Insulation: 31 mil heat and moisture resistant PVC
• Jacket: 6 mil nylon with SIMpull technology
• Approximate overall diameter: 0.253 in
• Approximate weight: 95 lb per 1000 ft (81 lb copper)
• Temperature ratings: THHN/THWN-2 90C; MTW; AWM (sizes 14 through 6 AWG)
• Listings and standards: UL 83, UL 758, UL 1063; VW-1 and FT-1 flame ratings; RoHS compliant

Southwire designs SIMpull conductors to be installed without a pulling lubricant, which helps on long conduit runs. Allowable temperatures are 90C for THHN and THWN-2 conductors, with MTW and AWM ratings as listed above. Verify the conductor color, size and code requirements for your project before ordering THHN wire. Contact Millennium for current pricing, availability and lead time.
